Truck and car tyre changer and wheel balancer AE897+CB460B

TRUCK AND CAR TYRE CHANGER HEAVY DUTY AE897 FROM BRIGHT

As rim safety becomes more and more important, When workshop safety and efficiency became more and more important, 897 came into being. After three years of continuous market research and development and improvement, Rome is finally built. High efficiency work, covering the full range of workshop requirements of worker protection, high efficiency at low cost without compromise.

Highlights

The tyre changer adopts the tilting back structure, and the forward and backward tilt of the column are all controlled and locked by pneumatic control.

Standard 200mm large cylinder matched with variable torque arm, bead breaker force is stronger, is suitable for all kinds of hard rubber tires, explosion-proof tires.

Special assisting arm, upper and lower press roller can run independently, easy to operate, high efficiency.

Equipped with tyre lifting arm, auxiliary loading and unloading tires, reduce labour intensity.

Technical data

Rim diameter 12” - 30” inch
Rim width 3"--14"inch
Max wheel diameter 43"inch
Working pressure 8 - 10 bar
Bead breaking force 2800Kg
Powers supply 110V/220V/380V
Motor Power 0.75Kw/1.1Kw
Rotation per minute 6.5/13rpm
Noise ＜70dB
Machine dimensions 1950×1850×2150 mm
Packing dimensions 1230x1150x1850 mm

WHEEL BALANCER CAR, ALL COMMERCIAL VEHICLES AND TRUCKS CB460B

The AECB46B is the perfect balancer for the workshop requiring a space saving performance oriented tyre balancer to suit both cars and truck. The bigger display panel is easy to read and giver the operator instructions that give a clear step by step process making it both easier to use and faster to operate

Highlights

The balancer has independent intellectual property rights. LED display

The machine can balance both car wheel and truck wheel. Customer can customize
display of imbalance in 5 or 10. Three ALU balancing programs and STA balancing program.
Manual brake for easy application of weight.

The machine can change display from inch to millimetre, gram to ounce. The machine is integrated with pneumatic lift, efficiently and labour-saving.

Clear digital tube display windows, make the data more visually direct from viewing.

Technical data

Rim diameter 10” - 24” inch
Max wheel weight 200 kg
Max wheel diameter 1200mm
Rim width 1,5” - 20”
Precision ±1g (car)/±10g (truck)
Motor Power 0.55kW
Power supply 100/230V 1ph
Rotation per minute 100rpm (car)/200rpm (truck)
Balancing time 9s (car) / 20s (truck)
Second time mounting test ≤5g
Machine dimensions 1330x1280x1320 mm
Packing dimension 1300x990x1190 mm
Net weight 220 kg
Gross weight 270 kg
